Products Main Pages Best Sellers Total Phase: Beagle™ I²C/SPI/MDIO Protocol Analyser £230.00 / €287.50 The versatile Beagle I2C/SPI/MDIO Protocol Analyzer is the ideal tool for the embedded engineer who is developing an I2C, SPI, or MDIO based product.
find out more Total Phase: Aardvark™ I²C/SPI Host Adapter £195.00 / €243.75 Connect your Windows or Linux PC to I2C and SPI bus through USB with the Aardvark I2C/SPI Host Adapter. Multi-master, slave, and GPIO are featured in this versatile development and testing tool.
find out more Total Phase: Beagle™ USB 480 USB v2 Protocol Analyser £850.00 / €1,062.50 The Beagle™ USB 480 Protocol Analyzer is a low cost, non-intrusive High-Speed USB 2.0 bus monitor which comes complete with software and royalty-free API.
The Beagle analyzer is capable of capturing, displaying and filtering high-speed USB bus-states and traffic in real-time with timing at 16.7 ns resolution. Thanks to an on-board 64 MB buffer, sustained bursts of 480 Mbps traffic can be captured with no loss of data.
find out more Macraigor Systems: The Genuine Macraigor Wiggler™ Low-Cost Parallel Host Adapter £152.00 / €190.00 The Wiggler is a low cost interface used in the design, debug and programming of microprocessor and microcontroller-based embedded systems. One side of the Wiggler interfaces to the parallel port of a host PC and the other side connects to an OCD (on-Chip Debug) port on the target system. As with all Macraigor interface devices, the Wiggler can simultaneously debug up to 255 devices on a single scan chain.
find out more Byte Paradigm: Wave Generator Xpress Digital Pattern Generator  £350.00 / €437.50 The Wave Generator Xpress is high speed USB 2.0 PC-based digital pattern generator or arbitrary digital waveform generator. It generates arbitrary digital stimuli on up to 16 bits, 100 MByte depth per run at up to 50 MSample/s.
This USB pattern generator features 6 digital control lines used to handle output / input clock signals and generate repetitive sequences. It is typically used to generate arbitrary digital data to stimulate your board or chip prototype, exercise custom digital interfaces and produce arbitrary digital sample streams to your system under test. Wave Generator Xpress is a convenient, robust and compact personal tool for a wide variety of test and debug tasks on electronic systems.
The Wave Generator Xpress is controlled with the 8PI Control Panel Software, freely licensed with the ADWG (Arbitrary Digital Waveform Generator) mode of operation. With its multiple graphical and programming (TCL/tk and C/C++) interfaces, you have many flexible options to generate stimuli, from binary or text file to whole algorithms programmed in Tcl/tk, C/C++, Visual Basic and many others.
find out more  Leap Electronic: Leaper-48 Universal Hand-Held Device Programmer with USB Interface £315.00 / €393.75 The Leaper-48 is a compact professional 48 pin universal programmer with a USB interface to the host PC. Supports EPROMs, EEPROMs, FLASH EPROMs, serial EEPROMs, Microcontrollers, GALs and PALCEs, PLD's and DSP's.
find out more |  Electronic Development ToolsProfessional development tools for the electronic design and software engineer.
The Debug Store stocks a wide range of embedded development tools and electronic test equipment for the embedded hardware and software developer. We source tools from some of the best tools developers worldwide and are able to offer excellent value for money and responsive pre and after sales service by our professional staff with over 20 years of embedded design experience. If you have any questions about our products or embedded development in general - just ask!
We will tell you on the site if a product is in stock or how long it will take to be delivered.
|
New ProductsLineeye: LE-8200-E Compact Protocol Analyser £2,995.00 / €3,743.75 LE-8200-E is a compact protocol analyzer equipped as standard with Max. online monitoring, simulation, and BERT. It enables a measurement test for a communication circuit at max. 4Mbps. It is battery powered making it ideal for field applications.
It is fitted with a colour LCD
find out more | | Paradigm Systems: Tern Development Kit to Paradigm PRO/REAL Package £675.00 / €843.75 If you wish to design your own x86 hardware, then you can upgrade the Tern Development Kit to the full Paradigm PRO/REAL Package (normal price GBP1,330). This wil allow you to port the PDREMOTE monitor to your own hardware and also adds the following additional features:
+ PC-lint (a GBP 125 value) integrated into the IDE
+ VisualAssist (source code database and productivity enhancement)
+ PDREMOTE/ROM source code (customize your PDREMOTE/ROM builds)
+ RTOS integration
+ Version control integration
find out more | | Xeltek: SuperPro 5000 144 pin Universal Programmer with USB Interface £1,090.00 / €1,362.50 The SuperPro 5000 is capable of ultra high-speed programming of advanced devices such as high capacity NAND Flash devices as it incorporates a fast 32-bit RISC CPU device.
The SP-5000 incorporates 144 universal pin drivers and can work in stand-alone or PC-connected mode. This makes it ideal for the lab or production (a gang version, the SP-5004GP is also available). It also improves the value of the investment as larger devices can be programmed. Devices with a Vcc of 1.2V to 5V are supported.
An extensive range of adapters are available for the SP-5000 and a 48 pin DIP adapter is included.
find out more | | Janatek: Logic-16 16 channels, 200MHz Logic Analyser and 16 Channel Pattern Generator £395.00 / €493.75 The La-Logic-16 is a sophisticated PC-based logic analyzer. It captures at a maximum of 200Mhz on its 16 channels simultaneously into it’s deep 1M samples/channel buffer.
It connects to the PC via the USB-port and does not require any external power.
The package is complete with all accessories included to start debugging immediately.
The pattern generator adds a new dimension to debugging possibilities. The 16-channel pattern generator can output data at rates up to 20 Mega-Patterns/second. The output pattern can be specified to come from a user file or from the easy to use ’Pattern Editor’. The La-Logic-16 operates as either a Logic analyzer or pattern generator.
find out more | | Artila: M-508 Linux Controller | | Tern: CAN-Engine™ Controller Board £81.00 / €101.25 The CAN-Engine™ (CANE) is a high performance, low cost, C/C++ programmable embedded controller with CAN support. It is intended for networking, automotive, industrial process control, high-speed data acquisition, and especially ideal for OEM applications.
find out more | | Xeltek: SuperPro 5004GP 4xGang 144 pin Universal Programmer with USB Interface £3,195.00 / €3,993.75 The SuperPro 5004GP is capable of ultra high-speed programming of up to 4 advanced devices concurrently, such as high capacity NAND Flash devices as it incorporates a fast 32-bit RISC CPU device.
The SP-5004GP incorporates 4 sets of 144 universal pin drivers and can work in stand-alone or PC-connected mode. This makes it ideal for the lab or production (a gang version, the SP-5004GP is also available). This enhances the value of the investment as larger devices can be programmed. Devices with a Vcc of 1.2V to 5V are supported.
An extensive range of adapters are available for the SP-5004GP and 4 x 48 pin DIP adapters are included.
find out more | | Macraigor Systems: usbWiggler™ Low Cost USB Host Adapter £215.00 / €268.75 The usbWiggler is a low-cost JTAG/BDM interface with a USB v2 PC connection used in the design, debug, and programming of microprocessor based embedded systems.
find out more | | Array Electronic: M3500A 6½ Digit Digital Multimeter £595.00 / €743.75 M3500A is a 6½ digit digital multimeter. It has 0.0015% 24-hour basic DC voltage accuracy at 10V range and 0.002% 24-hour basic resistance accuracy at 10kO range. At 6½digit, the multimeter delivers 50 triggered RDGS/sec via remote interface. At the fast 4½ digit, it reads over 2000 Readings/sec into its internal buffer.
find out more | | Macraigor Systems: Eclipse - free Embedded Development Environment
Macraigor Systems now offers you a free full Eclipse embedded debugging solution with example Eclipse projects that run on many (ARM, Xscale, MIPS32/64, TX49, PowerPC, AMCC, ...) standard evaluation boards.
find out more | | CCS: USB Development Kit | | CCS: Embedded Serial Busses Kit | | Dediprog: Race100 High Speed Gang programmer with 8 sockets £2,250.00 / €2,812.50 Race100 is a professional Gang Programmer dedicated and optimized for the Serial Flash memories. With the highest performance in the market and the highest concurrent socket number, it offers the lowest possible programming cost you could find in the market. The programming time is in average 8 times faster than the Universal programmers.
find out more | | CCS: CAN Bus Development Kit | | Duetronix: ProPro-40 Assembled Prototyping Board for 40pin PIC Devices £28.00 / €35.00 The ProtoPro-40 is supplied assembled. A 16F887 CPU may be fitted as an option. The board is 100mm x 80mm in size and is silk-screened, tin immersed and through hole plated.
Discounts available for quantity purchases.
find out more | |
|

|
